Model No.: FGYB5107
100% stainless steel fiber woven fabric, also known as high-temperature resistant metal woven fabric.
100% Stainless Steel Fiber Woven Fabric
100% stainless steel fiber woven fabric is a flexible metal textile made from fine metal fibers through a woven structure. It combines the flexibility of textile fabric with the durability, conductivity and environmental resistance of metallic materials.
Unlike conventional stainless steel wire mesh, stainless steel fiber woven fabric uses much finer fibers to create a soft and flexible structure. This makes it suitable for industrial applications where the material needs to conform to equipment surfaces, withstand demanding operating conditions or provide conductive and anti-static performance.
Fibemas supplies stainless steel fiber woven fabric for automotive glass forming molds, high-temperature conveyor applications, static electricity elimination and other industrial uses. Customized specifications are available according to equipment and application requirements.
| Parameter | Specification |
|---|---|
| Product Name | 100% Stainless Steel Fiber Woven Fabric |
| Material | 316L, FeCrAl |
| Fiber Diameter | Customized |
| Structure | Woven Fabric |
| Thickness | 0.4–0.6 mm |
| Conventional Width | 1000 mm (1 m) |
| Available Weight | 450 g/m², 550 g/m², 650 g/m², 800 g/m², 950–980 g/m² |
| Custom Width & Weight | Other widths and weights can be customized |
| Temperature Resistance | 650°C |
| Melting Point | 1350°C |
| Supply Form | Roll / Sheet |
| Surface Treatment | Available |
100% stainless steel fiber woven fabric is produced from fine metal fibers rather than conventional rigid stainless steel wires.
The woven fiber construction provides better flexibility and allows the fabric to adapt more easily to curved, irregular or equipment-specific surfaces.
This makes it suitable for industrial applications where a conventional rigid metal mesh may be difficult to install or use.
Flexible woven construction
Good mechanical durability
Electrical conductivity
Corrosion resistance
Reusable metal material
Adaptability to different industrial equipment
Customizable fiber and fabric structure
Automotive glass forming molds
Glass-processing equipment
Mold surface covering
Glass handling components
Industrial glass production equipment
Industrial conveyor equipment
Machinery contact surfaces
Equipment covering materials
Flexible metal components
Industrial processing systems
Specialized machinery components
Static electricity elimination in machinery
Anti-static industrial equipment
Conductive contact materials
Industrial grounding-related components
Static-sensitive production environments
Fibemas supplies customized stainless steel fiber woven fabric for different industrial equipment and production processes.
Material selection
Fiber diameter
Woven structure
Width
Roll or sheet supply
Surface treatment
Used as a flexible metal fabric for glass forming molds and related glass-processing equipment.
Suitable for machinery and equipment requiring flexible, conductive or durable woven metal materials.
Used in applications requiring electrical conductivity or the dissipation of accumulated static electricity.
Can be integrated into specialized conveyor or processing systems according to equipment requirements.
The customizable woven construction allows the material to be developed for application-specific industrial components.
Fibemas focuses on functional metal fiber materials for industrial applications.
For 100% stainless steel fiber woven fabric projects, we can support customization based on:
Application requirements
Equipment dimensions
Required fiber structure
Required width
Supply form
Surface treatment requirements
100% stainless steel fiber woven fabric is a flexible metallic textile made using fine metal fibers in a woven structure. It combines the flexibility of textile materials with the functional properties of metal fibers.
Stainless steel fiber woven fabric is made from much finer fibers and has a more flexible, textile-like structure. Conventional stainless steel wire mesh uses thicker metal wires and is generally more rigid.
Yes. Fibemas currently provides customization for material, fiber diameter, woven structure, width, supply form and surface treatment.
The current material options listed for this product are 304, 316L and FeCrAl.
The fabric can be supplied in roll or sheet form.
Yes. The width can be customized according to customer and equipment requirements.
Yes. Automotive glass forming mold covering is one of the applications currently listed for this product.
Yes. Stainless steel fiber woven fabric can be used in machinery and other industrial applications requiring conductive or static electricity dissipation properties.
Providing the intended application, equipment dimensions, preferred material, required width, fiber or woven structure requirements and quantity will help Fibemas evaluate the appropriate solution.
